GO GREEN! LOWER CARBON!
16.08kWh High-Capacity LiFePO4 Energy Storage
Power your home, business, solar system, or off-grid application with 16.08kWh of energy storage in a single 51.2V 314Ah battery. Advanced LiFePO4 battery technology delivers exceptional safety, reliability, and long service life.
8,500+ Cycles & Expandable Up to 241.2kWh
Designed for long-term energy independence, the Liniotech Energy 16kWh Power Tower delivers 8,500+ cycles at 80% depth of discharge (DoD) and supports up to 15 batteries in parallel, allowing your system to grow from 16.08kWh to approximately 241.2kWh.
Smart 200A BMS + WiFi Monitoring
A built-in intelligent 200A Battery Management System (BMS) continuously manages battery operation and protection. Integrated WiFi monitoring makes it easy to view battery information while broad inverter compatibility makes the Power Tower ideal for residential and commercial solar energy storage systems.
Take control of your energy with the Liniotech Energy 16kWh Power Tower Battery, a high-capacity 51.2V 314Ah LiFePO4 solar battery engineered for home energy storage, whole-home backup, off-grid solar systems, and commercial energy storage applications.
Delivering 16.08kWh of nominal energy per battery, the Power Tower combines long-life lithium iron phosphate technology with an intelligent BMS, WiFi real-time monitoring, and up to 200A maximum charge and discharge current. With a rated cycle life of 8,500+ cycles at 80% DoD, it is designed for years of dependable daily solar energy storage and backup power.
Need more capacity? The modular system supports up to 15 batteries connected in parallel, expanding from 16.08kWh to approximately 241.2kWh of battery storage. This makes the same platform suitable for everything from residential solar battery backup and off-grid homes to larger commercial and light-industrial energy storage projects.
The floor-standing Power Tower design incorporates wheels for easier positioning and installation. Broad hybrid inverter compatibility helps installers integrate the battery into new or existing 48V-class solar energy storage systems.
For safety, transportation, and international deployment, the battery is certified to CB IEC 62619, CE and UN38.3, with MSDS documentation available.
Whether you're looking for a 16kWh home battery, 48V LiFePO4 solar battery, whole-home backup battery, off-grid energy storage system, or scalable commercial battery storage solution, Liniotech Energy provides a powerful platform designed to grow with your energy needs.
Key Features
- 16.08kWh High-Capacity LiFePO4 Battery – 51.2V nominal voltage and 314Ah capacity provide substantial energy storage in one compact floor-standing battery for residential, solar, backup, and commercial applications.
- 8,500+ Long-Life Battery Cycles – Premium lithium iron phosphate battery technology is rated for more than 8,500 cycles at 80% DoD under specified test conditions, providing excellent longevity for daily solar cycling.
- Expandable to 241.2kWh – Connect up to 15 Liniotech Energy Power Tower batteries in parallel to build a scalable energy storage system ranging from 16.08kWh to approximately 241.2kWh.
- Smart 200A Battery Management System – Integrated BMS provides intelligent battery management and protection, with maximum charging and discharging currents up to 200A.
- WiFi Monitoring & Broad Inverter Compatibility – Monitor battery operation remotely while integrating with a wide range of compatible hybrid and off-grid solar inverters. Final inverter compatibility should be verified before installation.
- Mobile Floor-Standing Power Tower Design – Compact vertical enclosure with integrated wheels simplifies positioning and installation for home solar storage, whole-home backup, off-grid power, and commercial energy storage applications.
Product Specifications
| Specification | Liniotech Energy 16kWh Power Tower |
|---|---|
| Model | LNT-W-16K |
| Battery Chemistry | LiFePO4 – Lithium Iron Phosphate |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 314Ah |
| Nominal Energy | 16.08kWh |
| Operating Voltage | 46–56V DC |
| Maximum Charging Voltage | 56V DC |
| Maximum Charging Current | 200A |
| Maximum Discharging Current | 200A |
| Maximum Power | 7,680W |
| Cycle Life | ≥8,500 Cycles |
| Cycle Test Condition | 25±2°C, 0.5C/0.5C, 80% EOL |
| Designed Life | 10 Years |
| Parallel Expansion | Up to 15 Units |
| Maximum System Capacity | Approx. 241.2kWh |
| Monitoring | WiFi / Smart BMS |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | 0°C to 45°C |
| Enclosure Options | IP20 / IP65 |
| Dimensions (W × H × D) | 522.6 × 1007 × 343 mm / 20.6 × 39.6 × 13.5 in |
| Approx. Weight | 145.5 kg / 421 lbs |
| Certifications / Documentation | CB IEC 62619, CE, UN38.3, MSDS |
| Applications | Residential, Solar, Off-Grid, Backup, Commercial & Industrial Energy Storage |
