Solis S6-GC30K-LV-US 30kW Three Phase Inverter (208V) – Commercial Solar Power Solution
The Solis S6-GC30K-LV-US 30kW three phase inverter is a high-performance, commercial-grade solar inverter engineered for 208V three-phase rooftop solar systems. Designed for commercial and industrial PV projects, this advanced Solis inverter delivers industry-leading efficiency, intelligent monitoring, and robust safety features—making it one of the best choices for large-scale solar installations in the U.S.
With 97.7% max efficiency, AFCI protection, and 3 MPPT trackers, the Solis 30kW inverter maximizes energy production while ensuring long-term reliability in even the harshest environments.
Why Choose the Solis 30kW Three Phase Inverter?
- ✅ Optimized for 208V commercial solar systems
- ✅ Compatible with high-power solar panels (up to 20A string current)
- ✅ Built for harsh environments (NEMA Type 4X, C5 anti-corrosion)
- ✅ Advanced smart monitoring via SolisCloud
- ✅ Industry-leading safety features (AFCI, rapid shutdown, PID recovery)
Key Features of Solis S6-GC30K-LV-US Inverter
High Efficiency & Power Output
- Max efficiency: 97.7% (CEC 97.0%)
- Rated output: 30kW
- 1.5 DC/AC ratio for higher energy yield
- Wide MPPT voltage range for maximum solar harvesting
Advanced PV Compatibility
- Supports high current modules (up to 20A per string)
- Works with latest high-efficiency solar panels
- 3 MPPT design for multi-orientation rooftops
Industry-Leading Safety Protection
- Integrated AFCI (Arc Fault Circuit Interruption)
- Rapid shutdown transmitter (RSD compliant)
- Surge protection (DC & AC Type II)
- Anti-islanding, overcurrent, and temperature protection
Smart Monitoring & Remote Control
- Real-time monitoring via SolisCloud
- Supports WiFi, Ethernet, RS485, Cellular
- Remote firmware upgrades & diagnostics
- Intelligent I-V curve scanning & string monitoring
Built for Harsh Environments
- NEMA Type 4X enclosure
- C5 anti-corrosion rating
- Operating temp: -13°F to 140°F
- Ideal for coastal, industrial, and humid environments
Technical Specifications
| Specification | Details |
|---|---|
| Max Input Voltage | 1000V |
| Start-up Voltage | 195V |
| MPPT Trackers | 3 |
| Max Strings | 6 |
| Rated Output Power | 30 kW |
| Grid Voltage | 208VAC (3 Phase) |
| Max Output Current | 91.6A |
| Efficiency | 97.7% |
| Dimensions | 30.9" × 21.6" × 12.6" |
| Weight | 103.8 lbs |
| Cooling | Intelligent fan cooling |
| Protection Rating | Type 4X |
Built for Commercial & Industrial Solar Projects
The Solis 30kW inverter is specifically designed for:
- Commercial rooftops
- Industrial facilities
- Warehouses & factories
- Schools & office buildings
- Agricultural solar systems
Its wide voltage range, multi-MPPT design, and high DC/AC ratio make it ideal for maximizing ROI in commercial solar installations.
Certifications & Compliance
Fully compliant with U.S. and international standards:
- UL1741SB / UL1741SA
- IEEE 1547-2018
- NEC 690.12 (Rapid Shutdown)
- UL1699B (AFCI)
- California Rule 21
- FCC Part 15 Class B
- CAN/CSA C22.2
Protection & Reliability Features
- DC reverse polarity protection
- Short circuit protection
- Overcurrent & surge protection
- Grid monitoring & anti-islanding
- Temperature protection
- Integrated DC & AC disconnect switches
- Optional PID recovery for higher long-term yield
10-Year Warranty for Peace of Mind
The Solis inverter comes with a 10-year standard warranty, ensuring long-term performance and reliability for your solar investment.
